Epcos B43564-S9658-M3 B43564 Series Aluminum Electrolytic Capacitor, 6500 µF, 400V DC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Epcos (TDK) B43564-S9658-M3 is a high-capacity, long-life aluminum electrolytic capacitor engineered for demanding industrial power electronics. Belonging to the B43564 series, this screw-terminal component is optimized for high ripple current capability and exceptional reliability in frequency converters, UPS systems, and professional power supplies. The "S" prefix indicates a special design variation, frequently utilized in renewable energy applications such as wind power inverters. It features a charge-discharge proof design and a robust aluminum case with a PVC insulating sleeve, ensuring stable performance under continuous heavy-duty operation.
| Product ID | B43564-S9658-M3 |
| Capacitance | 6500 µF |
| Rated Voltage (VR) | 400V DC |
| Capacitance Tolerance | ±20% (M) |
| Reliability Grade | Long Life (LL) Grade |
| Terminal Type | Screw Terminals (High Current) |
| Case Construction | Polar aluminum case with insulating sleeve |
| Special Feature | Charge-discharge proof |
| Climatic Category | 25/085/56 (IEC 60068-1) |
| Operating Voltage Limit | 440V DC (Surge voltage VS) |
| Manufacturing Variant | -M3 (Specific mounting/terminal configuration) |
