ITELCOND AY(U)X-HR223X063BC1 Aluminum Electrolytic Capacitor, 22000uF, 63V
Regular price
$90.00 USD
Regular price
Sale price
$90.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The ITELCOND AY(U)X-HR223X063BC1 is an AY(U)X-HR screw-terminal aluminum electrolytic capacitor rated at 22000 µF and 63 V DC. This variant uses BC case code with 51 x 105 mm dimensions and -10%/+30% capacitance tolerance.
| Ordering Code | AY(U)X-HR223X063BC1 |
| Capacitance | 22000 µF |
| Rated Voltage | 63 V DC |
| Capacitance Tolerance | -10% / +30% |
| Case Code | BC |
| Case Size | 51 x 105 mm |
| Dissipation Factor | 0.24 @ 100 Hz |
| ESR Max | 17 mΩ @ 100 Hz |
| ESR Typical | 14 mΩ @ 100 Hz |
| Impedance Max | 13 mΩ @ 10 kHz |
| Ripple Current @ 55°C | 19.7 A @ 100 Hz |
| Ripple Current @ 85°C | 14.1 A @ 100 Hz |
| Terminal Type | Screw |
| Temperature Range | -40°C to +85°C |
| Climatic Category | 40/85/56 |
Apexon Supply provides B2B sourcing and replacement support for ITELCOND AY(U)X-HR223X063BC1. Buyers should compare the exact ordering code, capacitance, rated voltage, tolerance, case dimensions and electrical ratings against the original equipment requirements.
For RFQ support, submit ITELCOND AY(U)X-HR223X063BC1, required quantity and configuration requirements. Most qualified RFQs receive a response or quote within 12 hours.
