Siemens 6ES7322-1BH01-0AA0 SIMATIC S7-300 Digital Output SM 322 Module, 16 DO, 24V DC / 0.5A, isolated
Regular price
$125.00 USD
Regular price
Sale price
$125.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Siemens 6ES7322-1BH01-0AA0 is a high-reliability SIMATIC S7-300 digital output module (SM 322) designed for precise control of industrial actuators. This isolated module provides 16 digital outputs at 24V DC with a 0.5A rated current per channel, featuring electronic short-circuit protection and optocoupler potential separation to ensure maximum system availability and signal integrity in enterprise automation environments.
| Product ID (MPN) | 6ES7322-1BH01-0AA0 |
| Number of Digital Outputs | 16 |
| Rated Load Voltage (DC) | 24 V (Permissible range 20.4 V to 28.8 V) |
| Output Current (Rated) | 0.5 A |
| Total Current / Group | 4 A (Two groups of 8) |
| Short-circuit Protection | Yes; Electronic (Threshold 1 A) |
| Switching Frequency | 100 Hz (Resistive) / 0.5 Hz (Inductive) |
| Potential Separation | Yes; via Optocoupler |
| Required Front Connector | 20-pin |
| Dimensions (W x H x D) | 40 x 125 x 120 mm |
