Beckhoff EL3068 EtherCAT Terminal Analog Input, 0–10V, 8 Channels, 12×100×68 mm
Regular price
$340.00 USD
Regular price
Sale price
$340.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
The Beckhoff EL3068 is an 8‑channel analog input EtherCAT Terminal for 0…10 V signals. Each channel is digitized at 12‑bit resolution and transmitted to the controller with galvanic isolation between the E‑bus and signal voltage. The module provides high channel density in a 12 mm housing with per‑channel status LEDs.
Key Features
- Eight single‑ended analog inputs, 0…10 V
- 12‑bit conversion (16‑bit presentation incl. sign)
- Default conversion time 1.25 ms (configurable, multiplexed)
- Input filter limit frequency: 1 kHz; input impedance >130 kΩ
- 500 V electrical isolation (E‑bus/signal)
- Compact 12 mm IP20 terminal with LED indication
Applications
- Acquisition of 0–10 V process and sensor signals
- Space‑constrained control panels needing high channel density
Specifications
| Brand | Beckhoff |
| Series / Type | EtherCAT Terminal, analog input |
| Specific MPN | EL3068 |
| Number of Inputs | 8 (single‑ended, common 0 V reference) |
| Signal Voltage Range | 0…10 V |
| Resolution | 12 bit (16‑bit presentation incl. sign) |
| Conversion Time (default) | 1.25 ms (configurable, multiplexed) |
| Input Filter Limit Frequency | 1 kHz |
| Input Impedance | >130 kΩ |
| Electrical Isolation | 500 V (E‑bus / signal voltage) |
| Current Consumption (E‑bus) | typ. 130 mA |
| Dimensions (W × H × D) | 12 × 100 × 68 mm; IP20 |
