Bently Nevada 330130-045-00-05 3300 XL Extension Cable, 4.5 m, Standard Cable
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Bently Nevada 330130-045-00-05 is a 3300 XL Standard Extension Cable configured with a 4.5 metre (14.8 feet) cable length, standard cable, and Multiple Approvals option. For system configuration, the extension cable length and probe length must add together to equal the Proximitor Sensor total length.
| Part Number | 330130-045-00-05 |
| Product Type | 3300 XL Standard Extension Cable |
| Cable Length | 4.5 metres (14.8 feet) |
| Cable Option | Standard cable |
| Agency Approval Option | Multiple Approvals |
| Extension Cable Material | 75Ω triaxial, fluoroethylene propylene (FEP) insulated |
| Extension Cable Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Operating and Storage Temperature | -51 °C to +177 °C (-60 °F to +350 °F) |
| Connector Material | Gold-plated brass or gold-plated beryllium copper |
The 3300 XL 8 mm Proximity Transducer System is used for vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
Apexon Supply provides B2B sourcing and replacement support for Bently Nevada 330130-045-00-05, supporting procurement review, technical alignment, and industrial maintenance requirements.
Submit Bently Nevada 330130-045-00-05, required quantity, and application requirements for RFQ support. Most qualified RFQs receive a response or quote within 12 hours.
