Eaton Edison HCLR20 — HCLR Class CC Fuse, 20 A, 600 V, 200 kAIC, Non‑Indicating, Rejection Style — Pack of 10

The Eaton Edison HCLR20 is a Class CC cartridge fuse designed for branch‑circuit protection in industrial and commercial electrical systems. This non‑indicating, rejection‑style fuse is rated 20 A at 600 V with a 200 kA interrupting capacity (kAIC). Supplied in standard packaging as a pack of 10, the HCLR series provides reliable overcurrent protection in compact Class CC form factor.

Key specifications

• Manufacturer: Eaton Edison
• Catalog number: HCLR20
• Product type: Class CC cartridge fuse (HCLR series)
• Ampere rating: 20 A
• Voltage rating: 600 V
• Interrupting rating: 200 kAIC
• Fuse class: Class CC
• Indication: Non‑indicating
• Special features: Rejection style (prevents incorrect substitution)
• Quantity: 10 pieces per pack
• Physical dimensions (nominal): Length ≈ 1 in; Diameter ≈ 0.406 in
• Compliance & certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant

Features & benefits

• Compact Class CC footprint for space‑efficient fuse holders and panels.
• High interrupting rating (200 kAIC) suitable for high fault‑level systems.
• Rejection style prevents installation of incorrect fuse classes, improving safety and coordination.
• Non‑indicating design for general-purpose branch protection where remote/visual indication is not required.
• Eaton Edison manufacturing quality with recognized safety certifications.

Applications

• Branch‑circuit protection in motor control centers, panelboards, distribution panels, and industrial control systems.
• Retrofit and new install where Class CC compact design and high interrupting capability are required.

Installation & handling notes

• Install in holders rated for Class CC fuses. Do not substitute with fuses of different classes or characteristics.
• Verify proper coordination with upstream and downstream protective devices per system requirements.
• Follow Eaton product literature for installation torque and handling.

Ordering & packaging

• Pack of 10 (standard packaging). UPC: 782634420712.
