ebm-papst D2E146-AP47-22 Centrifugal Blower, 230 V AC, 2050/2550 rpm
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
ebm-papst D2E146-AP47-22 is a single-phase centrifugal blower designed as a built-in device for conveying air. Verified manufacturer data specifies 230 V AC operation at 50/60 Hz, 300/330 W power input, and rotational speeds of 2050/2550 min⁻¹.
| Brand | ebm-papst |
| Model | D2E146-AP47-22 |
| Motor | M2E068-EC |
| Product Category | Centrifugal Blower |
| Phase | Single-phase |
| Nominal Voltage | 230 V AC |
| Frequency | 50/60 Hz |
| Power Input | 300 W at 50 Hz / 330 W at 60 Hz |
| Current Draw | 1.31 A at 50 Hz / 1.45 A at 60 Hz |
| Rotational Speed | 2050 min⁻¹ at 50 Hz / 2550 min⁻¹ at 60 Hz |
| Motor Capacitor | 8 µF, 400 VDB |
| Minimum Back Pressure | 200 Pa at 50 Hz / 400 Pa at 60 Hz |
| Size | 146 mm |
| Ingress Protection | IP44, dependent on installation and position |
| Insulation Class | Class B |
| Impeller and Housing Material | Galvanised sheet steel |
| Motor Bearing | Ball bearing |
| Approvals | CCC, EAC |
| Installation Notes | Any mounting position. Wiring: U1 blue, Z brown, U2 black, PE green/yellow. |
This centrifugal blower is typically used for controlled air movement, forced-air cooling, ventilation, and thermal management in industrial equipment and machinery.
Apexon Supply provides B2B sourcing and replacement support for ebm-papst D2E146-AP47-22. Buyers should verify voltage, frequency, back-pressure requirements, mounting dimensions, airflow direction, wiring, and operating conditions before replacement.
Send the MPN, required quantity, and application requirements for B2B RFQ support and technical alignment.
