ELECTRONICON E62.C58-102E10 E62 Series Heavy Duty AC Capacitor, 1µF, 1200V AC

$80.00 USD

Sale Sold out

Shipping calculated at checkout.

Pack Size 1 pcs 6 pcs 12 pcs

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

The ELECTRONICON E62.C58-102E10 is a heavy-duty AC/DC film capacitor from the universal E62 series, designed for demanding power electronics applications. It features a hermetically sealed aluminum can filled with environmentally friendly plant oil and is optimized for high RMS currents, making it suitable for non-sinusoidal voltages, pulsed currents, damping, commutation, and AC filter circuits. The integrated break-action mechanism (BAM) ensures safe, controlled disconnection in case of overload.

Key Features

Heavy-duty AC capacitor for universal and high-current applications.
Hermetically sealed aluminum can with plant oil filling (standard).
Integrated overpressure protection (Break-Action Mechanism - BAM™).
Optimized for high RMS and surge currents (I_max: 25A, Î: 0.8kA).
Self-healing metallized polypropylene (MKP) dielectric.
Complies with IEC 61071, UL810, and CSA 22.2 No.190 standards.
Compact E1/E2 design with tab terminals.

Specifications

Product ID / Ordering Code	E62.C58-102E10
Rated Capacitance (C_N)	1 µF
Rated AC Voltage (U_N)	1200V AC
RMS Voltage (U_rms)	850V
Surge Voltage (U_S)	3000V
DC Test Voltage (U_TC)	4000V AC
Equivalent Series Resistance (DCR_S)	6 mΩ
Thermal Resistance (R_th)	25.6 K/W
Max. Continuous Current (I_max)	25 A
Max. Surge Current (Î)	0.8 kA
Short Circuit Current (I_S)	2.5 kA
Equivalent Series Inductance (L_e)	100 nH
Dimensions (D₁ × L₁)	30 × 58 mm
Design / Terminal	E1/E2 (6.3 × 0.8 mm tab)
Weight	0.05 kg
Operating Temperature Range	-40 ... +85°C
Hotspot Temperature (Θ_HOTSPOT)	≤ 85°C
Capacitance Tolerance	±10% (optional ±5%)
Dissipation Factor (tanδ₀)	2 × 10^-4
Mounting Position	Terminals pointing upwards (vertical)
Standards	IEC 61071, UL810, CSA 22.2 No.190
