ELECTRONICON E62.D81-402E20 E62 Series Heavy Duty AC Capacitor, 4µF, 1000V AC

$125.00 USD

Sale Sold out

Shipping calculated at checkout.

Pack Size 1 pcs 6 pcs 12 pcs

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

The ELECTRONICON E62.D81-402E20 is a heavy-duty AC/DC film capacitor from the universal E62 series, designed for demanding power electronics applications. It features a hermetically sealed aluminum can filled with environmentally friendly plant oil and is optimized for high RMS currents, making it suitable for non-sinusoidal voltages, pulsed currents, damping, commutation, and AC filter circuits. The integrated break-action mechanism (BAM) ensures safe, controlled disconnection in case of overload.

Key Features

Heavy-duty AC capacitor for universal and high-current applications.
Hermetically sealed aluminum can with plant oil filling (standard).
Integrated overpressure protection (Break-Action Mechanism - BAM™).
Optimized for high RMS and surge currents (I_max: 45A, Î: 1.3kA).
Self-healing metallized polypropylene (MKP) dielectric.
Complies with IEC 61071, UL810, and CSA 22.2 No.190 standards.
Compact E1/E2 design with tab terminals.

Specifications

Product ID / Ordering Code	E62.D81-402E20
Rated Capacitance (C_N)	4 µF
Rated AC Voltage (U_N)	1000V AC
RMS Voltage (U_rms)	720V
Surge Voltage (U_S)	2500V
DC Test Voltage (U_TC)	3500V AC
Equivalent Series Resistance (R_S)	5.8 mΩ
Thermal Resistance (R_th)	15.7 K/W
Max. Continuous Current (I_max)	45 A
Max. Surge Current (Î)	1.3 kA
Short Circuit Current (I_S)	2.9 kA
Equivalent Series Inductance (L_e)	80 nH
Dimensions (D₁ × L₁)	35 × 81 mm
Design / Terminal	E2 (6.3 × 0.8 mm tab)
Weight	0.1 kg
Operating Temperature Range	-25 ... +85°C
Hotspot Temperature (Θ_HOTSPOT)	< 85°C
Capacitance Tolerance	±10% (optional ±5%)
Dissipation Factor (tanδ₀)	2 × 10^-4
Mounting Position	Terminals pointing upwards (vertical)
Standards	IEC 61071 (optional IEC 61881)
