ELECTRONICON E62.S19-563L302 E62-3ph Heavy Duty Three Phase AC Filter Capacitor, 55.7 µF, 1080V AC

Overview: The ELECTRONICON E62-3ph series is a premium line of heavy-duty three-phase AC filter capacitors engineered for severe operating conditions. This model is designed for high AC-voltage load capacity, featuring a low series resistance and small self-inductance to handle high RMS and surge currents essential for AC filtering, harmonic filtering, and power factor correction in applications like wind power and UPS systems. The three capacitor elements are internally connected in delta and filled with plant oil for effective heat dissipation and insulation.

• Robust Performance: Built for heavy-duty operation in sophisticated environments with high harmonic distortion.
• Optimized Electrical Characteristics: Low ESR and ESL design ensures high current strength for filter applications.
• Advanced Safety Features: Incorporates a self-healing dielectric and an integrated overpressure protection (BAM™) for safe, controlled disconnection.
• Long Service Life: Offers a statistical lifetime exceeding 200,000 hours with a failure rate of 100 FIT.
• Secure Connection: Features IP20-rated, finger-proof CAPAGRIP™ screw terminals for reliable and simple installation.
