EPCOS B25620B1427K101 B2562* Series MKP DC Link Film Capacitor, 420µF, 1100VDC - Pack of 4
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The EPCOS B25620B1427K101 is a high-performance MKP (Metallized Polypropylene) film capacitor from the B2562* series, specifically designed for DC link applications in power electronics. This capacitor features a capacitance of 420µF and a rated DC voltage of 1100V. It is engineered for exceptional reliability with a service life of 100,000 hours, featuring a very low dielectric dissipation factor and low self-inductance. Housed in a robust aluminum case with an M12 mounting stud and filled with dry-type, non-PCB polyurethane resin, it is optimized for high RMS current handling. This makes it an ideal component for inverters, converters, and other demanding power electronic circuits.
| Product ID / Order Code | B25620B1427K101 |
| Manufacturer | EPCOS (TDK) |
| Series | B2562* (MKP DC) |
| Rated Capacitance (C_R) | 420 µF |
| Capacitance Tolerance | ±10% (K) |
| Rated DC Voltage (V_RDC) | 1100 V DC |
| Test Voltage Terminals (V_TT) | 1650 V DC, 10 s |
| Test Voltage Terminals to Case (V_TC) | 4000 V AC, 10 s |
| Max RMS Current (I_MAX) | 75 A |
| Max Surge Current (I_s) | 17.3 kA |
| Max Peak Current (î) | 5.8 kA |
| ESR (at 1 kHz, typical) | ≤ 1.7 mΩ |
| Self Inductance (L_self) | ≤ 40 nH |
| Thermal Resistance (R_th) | 2.4 K/W |
| Dielectric Dissipation Factor (tan δ₀) | 2·10⁻⁴ |
| Service Life Expectancy | 100,000 h at T_hs +75 °C and V_RDC |
| Climatic Category | 55/85/56 |
| Operating Temperature Range | -55 °C to +85 °C |
| Diameter (D) | 85 mm |
| Case Height (H_c, typical) | 155 mm |
| Total Height (H_T) | 161 mm |
| Weight (approx.) | 1.0 kg |
| Terminals | Female M6 |
| Mounting | M12 threaded stud |
| Degree of Protection | IP00 (Indoor mounting) |
| Reference Standards | IEC 61071 |
