EPCOS B25620B0287K701 B2562* Series MKP DC Link Film Capacitor, 280µF, 700VDC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The EPCOS B25620B0287K701 is a high-performance MKP (Metallized Polypropylene) film capacitor from the B2562* series, designed for demanding DC link applications in power electronics. This component offers a high capacitance of 280µF with a rated DC voltage of 700V. It is engineered for a long service life of up to 100,000 hours and features a very low dielectric dissipation factor. Housed in a robust aluminum case with an M12 mounting stud, it utilizes a dry-type, non-PCB polyurethane resin filling. With its high RMS current handling and low self-inductance, this capacitor is ideal for inverters, converters, and other power electronic circuits requiring reliable energy storage and filtering.
| Product ID / Order Code | B25620B0287K701 |
| Manufacturer | EPCOS (TDK) |
| Series | B2562* (MKP DC) |
| Rated Capacitance (C_R) | 280 µF |
| Capacitance Tolerance | ±10% (K) |
| Rated DC Voltage (V_RDC) | 700 V DC |
| Test Voltage Terminals (V_TT) | 1050 V DC, 10 s |
| Test Voltage Terminals to Case (V_TC) | 4000 V AC, 10 s |
| Max RMS Current (I_MAX) | 55 A |
| Max Surge Current (I_s) | 9.1 kA |
| Max Peak Current (î) | 3 kA |
| ESR (at 1 kHz, typical) | ≤ 1.4 mΩ |
| Self Inductance (L_self) | ≤ 40 nH |
| Thermal Resistance (R_th) | 4 K/W |
| Service Life Expectancy | 100,000 h at T_hs +75 °C and V_RDC |
| Climatic Category | 55/85/56 |
| Operating Temperature Range | -55 °C to +85 °C |
| Diameter (D) | 85 mm |
| Case Height (H_c) | 70 mm |
| Total Height (H_T) | 76 mm |
| Weight (approx.) | 0.45 kg |
| Terminals | Female M6 |
| Mounting | M12 threaded stud |
| Degree of Protection | IP00 (Indoor mounting) |
| Reference Standards | IEC 61071 |
