EPCOS B32362A4606J080 FilterCap MKP AC Capacitor, 60µF, 480V/680V
Regular price
$50.00 USD
Regular price
Sale price
$50.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The EPCOS B32362A4606J080 is a high-power film capacitor from the FilterCap MKP AC series, designed for single-phase AC filtering and power electronic applications. It features a metallized polypropylene dielectric, self-healing technology, and an overpressure disconnector for safety. With a capacitance of 60µF and ratings of 480V RMS / 680V DC, it is built for reliability in demanding industrial environments.
- Metallized Polypropylene (MKP) Film Dielectric
- Self-Healing Technology & Overpressure Disconnector
- High Current Capability: 30A RMS, 1150A Peak Surge (Is)
- Low Equivalent Series Resistance (Rs): 3.2 mΩ
- Designed for General Purpose AC Filtering Applications
- RoHS, UL 810, IEC 61071 Compliant
| Product ID / Ordering Code | B32362A4606J080 |
| Brand | EPCOS (TDK) |
| Series / Type | FilterCap MKP AC – Single Phase (B32362 Series) |
| Rated Capacitance (CR) | 60 µF |
| Capacitance Tolerance | ±5% (J) |
| Rated AC Voltage (VRMS) | 480 V |
| Rated DC Voltage (VRDC) | 680 V |
| Maximum RMS Current (Imax) | 30 A |
| Maximum Peak Current (Î) | 1150 A |
| Surge Current (Is) | 3.4 kA |
| Series Resistance (Rs) | 3.2 mΩ |
| Self Inductance (Lself) | 185 nH |
| Dissipation Factor (tan δ @ 100Hz) | ≤ 1.0 x 10⁻³ |
| Terminal Type | M10 Screw Terminals (2x) |
| Dimensions (D x H) | 75 mm x 117 mm |
| Weight (Approx.) | 0.7 kg |
| Operating Temperature (Tmax / Ths) | +70°C / +85°C |
| Storage Temperature (Tstg) | -40°C to +85°C |
| Climatic Category | 40/70/21 |
| Safety / Standards | IEC 61071, UL 810 (File E106388), RoHS, CE |
