TDK B32373A3257J030 B32373 Series FilterCap MKD-AC Capacitor, 250µF, 330VAC
Regular price
$80.00 USD
Regular price
Sale price
$80.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview: The TDK B32373A3257J030 is a high-power film capacitor from the B32373 series, part of the FilterCap MKD-AC single-phase range for general-purpose applications. It features a 250µF rated capacitance and a 330VAC (460VDC) voltage rating, housed in a robust aluminum can with M10 screw terminals. Utilizing metallized polypropylene film and self-healing technology, this capacitor is designed for high reliability, low losses, and long service life in demanding power electronic environments such as motor drives and power supplies.
Key Features:
- Metallized polypropylene film dielectric with self-healing technology
- High-power M10 screw terminals for secure, high-current connections (100A max)
- Long life expectancy: 100,000 hours at rated voltage and +85°C hot-spot
- Low dissipation factor (tan δ ≤ 1.0 x 10⁻³ at 100Hz)
- Non-PCB, soft polyurethane resin filling
- Overpressure disconnector safety device; naturally air-cooled
- Safety approvals: UL 810, CSA C22.2 No. 190 (Protected, 10k AFC)
| Product ID / Ordering Code | B32373A3257J030 |
| Series | B32373 (Type A) |
| Capacitance (CR) | 250 µF |
| Rated AC Voltage (VRMS) | 330 V |
| Rated DC Voltage (VRDC) | 460 V |
| Capacitance Tolerance | ±5% (J) |
| Maximum Current (Imax) | 60 A |
| Maximum Peak Current (Î) | 3600 A |
| Case Dimensions (D x H) | 85 mm x 195 mm |
| Terminal Type | M10 Screw (2x) |
| Approx. Weight | 1.30 kg |
| Dissipation Factor (tan δ @ 100Hz) | ≤ 1.0 x 10⁻³ |
| Operating Temperature Range (Tmax) | -40°C to +70°C (Ambient) |
| Maximum Hot-Spot Temperature (Ths) | +85°C |
| Climatic Category (IEC 60068-1) | 40/70/21 |
| Reference Standards | IEC 61071, GB/T 17702, UL 810 |
