EPCOS B43564-S9588-M2 Aluminum Electrolytic Capacitor, 5800µF 400V, Screw Terminal
Regular price
$55.00 USD
Regular price
Sale price
$55.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The EPCOS B43564-S9588-M2 is an industrial-grade, large-can aluminum electrolytic capacitor engineered for mission-critical power electronics systems. This high-capacity component is optimized for DC link filtering in frequency converters and industrial power supplies, featuring a robust screw terminal design for secure, low-resistance connections and an exceptionally long service life in high-ripple current environments.
| Product ID (MPN) | B43564-S9588-M2 |
| Order Code | B43564S9588M2 |
| Capacitance | 5800 µF |
| Rated Voltage | 400 VDC |
| Capacitance Tolerance | ±20% (M) |
| ESR (Typical) | ≤ 21 mΩ (100 Hz, 20 °C) |
| Useful Life | 12,000 hours at +85 °C |
| Terminal Type | Screw Terminals |
| Product Series | B43564 Long Life Series |
| Compliance | IEC 60384-4 |
