Ferraz Shawmut FD20GD150V25 Semiconductor Fuse, 25 A, 1500 VDC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Ferraz Shawmut FD20GD150V25, item number A080431, is a 25 A Protistor high-speed cylindrical semiconductor fuse rated for 1500 VDC. This 20 x 127 mm gR fuse has a gRD design, no indicator, a 30 kA DC breaking capacity, and 12 W power dissipation at rated current.
| Manufacturer Part Number | FD20GD150V25 |
| Item Number | A080431 |
| Brand | Ferraz Shawmut / Mersen |
| Series | Protistor 20x127 gR |
| Rated Current | 25 A |
| Rated Voltage | 1500 VDC |
| Rated Breaking Capacity | 30 kA DC |
| Fuse Characteristic | gR |
| Design | gRD |
| Product Size | 20 x 127 mm |
| Indicator | Without indicator |
| Power Dissipation at Rated Current | 12 W |
| Recognition and Standard | UL recognized; IEC 60269-4 compliant |
Typical applications: The FD20GD150V25 is used for DC control circuits and auxiliary circuits supporting measuring and monitoring devices where fast-acting semiconductor protection is required.
B2B sourcing support: Apexon Supply supports procurement review, replacement sourcing, and technical alignment for the Ferraz Shawmut FD20GD150V25. Confirm the item number, rated current, DC voltage, breaking capacity, fuse characteristic, dimensions, and indicator configuration against the original equipment requirements.
RFQ instructions: Send the MPN, item number, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
