Mersen A13X250-4 Amp-trap Form 101 Semiconductor Protection Fuse, 250A, 130V AC/100V DC
Regular price
$125.00 USD
Regular price
Sale price
$125.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mersen A13X250-4 is a high-performance Amp-trap Form 101 semiconductor protection fuse engineered for the high-speed protection of diodes, thyristors, and other sensitive semiconductor devices. Featuring a compact bolt-in blade design, this fast-acting fuse provides exceptional current-limiting capabilities and low I²t to minimize component damage during short-circuit events in rectifiers and heavy-duty industrial power equipment.
| Product ID (MPN) | A13X250-4 |
| Current Rating | 250A |
| Voltage Rating (AC) | 130 VAC |
| Voltage Rating (DC) | 100 VDC |
| Interrupting Rating (AC) | 8kA I.R. |
| Interrupting Rating (DC) | 10kA I.R. |
| Fuse Characteristic | Fast-Acting, Current Limiting |
| Melting I²t | 10,000 A²s |
| Clearing I²t (at 130V) | 50,000 A²s |
| Watts Loss at Rated Current | 12 W |
| Mounting Type | Type 4 (Blades, Bolt-in) |
| Overall Length | 2.66 in (67.6 mm) |
| Body Diameter | 1.13 in (28.7 mm) |
