Mersen A6T15 Class T Fast-Acting Power Fuse, 15A, 600VAC / 300VDC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mersen A6T15 is an Amp-Trap® Class T fast-acting power fuse rated 15 A, 600 VAC, and 300 VDC. Its compact glass-melamine body measures 1.50 × 0.57 in (38.1 × 14.5 mm) and provides high current limitation for circuit protection applications.
| Catalog Number | A6T15 |
| Fuse Class | Class T |
| Operating Characteristic | Fast acting |
| Ampere Rating | 15 A |
| Voltage Rating | 600 VAC / 300 VDC |
| Interrupting Rating | 200 kA AC / 100 kA DC |
| Body Material | Glass melamine |
| Dimensions A × B | 1.50 × 0.57 in (38.1 × 14.5 mm) |
| Approvals and Standards | UL 248-15, File E2137; CSA C22.2 No. 248.15; DC listed to UL 248 |
Verified applications for A6T Class T fuses include loadcenters, panelboards, switchboards, circuit breakers, and metering centers.
Apexon Supply provides B2B sourcing, replacement support, and technical alignment for industrial circuit-protection components used in electrical distribution and maintenance systems.
Submit catalog number A6T15, the required quantity, and application requirements to request a B2B quote and procurement review.
