Mersen AJT175 Amp-Trap 2000 Class J Time-Delay Fuse, 175 A, 600 V AC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mersen AJT175 is an Amp-Trap 2000® Class J time-delay power fuse rated at 175 A, 600 V AC, and 400 V DC. This non-indicating fuse is designed to handle motor-starting and transformer-inrush currents while providing current-limiting circuit protection.
| Catalog Number | AJT175 |
| Ampere Rating | 175 A |
| Rated Voltage AC | 600 V AC |
| Rated Voltage DC | 400 V DC |
| Self-Certified Rated Voltage AC | 700 V AC |
| Interrupting Rating AC | 200 kA |
| Interrupting Rating DC | 100 kA |
| Fuse Class | Class J |
| Time Characteristic | Time delay |
| Indicator Version | Non-indicating |
| Dimension A | 5-3/4 in (146 mm) |
| Dimension B | 1-5/8 in (41 mm) |
| Approvals and Standards | UL 248-8, UL 248 DC listing, CSA C22.2 No. 248.8, IEC 60269-2-1 |
Typical applications: Motor circuits, mains, feeders, branch circuits, transformers, control panels, circuit-breaker back-up, bus duct, load centers, and lighting, heating, or general loads.
Apexon Supply provides B2B sourcing and replacement support for Mersen circuit-protection components, including technical identification and procurement alignment.
Submit Catalog Number AJT175, the required quantity, and application requirements for RFQ support. Most qualified RFQs receive a response or quote within 12 hours.
