Ferraz Shawmut FR22GC69V25 B220916 Semiconductor Fuse, 25 A, 690 VAC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Ferraz Shawmut FR22GC69V25, reference number B220916, is a 25 A, 690 VAC Protistor semiconductor fuse with a 22 x 58 mm ferrule body and gRC operating class. It is designed for semiconductor and power-electronics circuit protection.
| Brand | Ferraz Shawmut |
| Catalog Number | FR22GC69V25 |
| Reference Number | B220916 |
| Product Type | Protistor semiconductor ferrule fuse |
| Fuse Class | gRC |
| Current Rating | 25 A |
| Voltage Rating | 690 VAC |
| Tested Breaking Capacity | 100 kA at 690 V |
| Pre-Arcing I²t at 1 ms | 39 A²s |
| Total Clearing I²t at Rated Voltage | 280 A²s |
| Power Loss | 4.5 W at 0.8 In; 7.5 W at In |
| Dimensions | 58 mm length x 22.2 mm diameter |
| Trip Indicator | Without trip indicator |
Typical applications: Semiconductor protection, power-electronics equipment, drive circuits, rectifiers, inverters, low-voltage equipment, and coordinated circuit-protection assemblies.
Apexon Supply provides B2B sourcing and replacement support using both catalog number FR22GC69V25 and reference number B220916. Buyers should verify the 25 A rating, 690 VAC rating, gRC class, 22 x 58 mm body size, and circuit coordination requirements before replacement.
Send the catalog number, reference number, required quantity, and application requirements to request a B2B quote and technical alignment support.
