HANYOUNG NUX SSR-2D103Z Single-Phase Solid State Relay, 10 A, 24-380 VAC
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The HANYOUNG NUX SSR-2D103Z is a single-phase solid state relay with DC input and AC load switching. This exact model is rated for a 10 A load current and 24-380 VAC load voltage.
| Model | SSR-2D103Z |
| Rated Load Current | 10 A |
| Load Voltage | 24-380 VAC |
| Rated Input Voltage | 5-24 VDC |
| Operating Input Voltage | 4.6-32 VDC |
| Frequency | 50/60 Hz |
| Leakage Current | 20 mA max. |
| Output ON Voltage Drop | 1.6 V RMS max. |
HANYOUNG NUX specifies the SSR-2 series for resistive loads.
Apexon Supply provides B2B sourcing and replacement support for HANYOUNG NUX SSR-2D103Z to assist industrial buyers with procurement review and technical alignment.
Send the SSR-2D103Z, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
