HANYOUNG NUX SSR-2D703Z Single-Phase Solid State Relay, 70 A, 24-380 VAC
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The HANYOUNG NUX SSR-2D703Z is a single-phase solid state relay with DC input and AC load switching. This exact model is rated for a 70 A load current and 24-380 VAC load voltage and uses zero-cross switching.
| Model | SSR-2D703Z |
| Rated Load Current | 70 A |
| Load Voltage | 24-380 VAC |
| Rated Input Voltage | 5-24 VDC |
| Operating Input Voltage | 4.6-32 VDC |
| Frequency | 50/60 Hz |
| Leakage Current | 20 mA max. |
| Output ON Voltage Drop | 1.6 V RMS max. |
| Switching Method | Zero-cross switching |
| Applicable Standard | IEC 62314 |
HANYOUNG NUX specifies the SSR-2D703Z for resistive-load applications.
Apexon Supply provides B2B sourcing and replacement support for HANYOUNG NUX SSR-2D703Z to assist industrial buyers with procurement review, technical comparison, and replacement sourcing.
Send the SSR-2D703Z, required quantity, and application requirements to request a B2B quote and technical alignment support. Most qualified RFQs receive a response or quote within 12 hours.
