Hinode 1000GH-20UL High-Speed Fuse, 20 A, AC/DC 1000 V
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Hinode 1000GH-20UL is a 20 A cylindrical high-speed fuse designed for semiconductor and industrial power circuit protection. Verified 1000GH series specifications include AC/DC 1000 V operation, 100 kA breaking capacity, 30 A²s pre-arcing I²t, and UL recognition.
| Brand | Hinode |
| Manufacturer Part Number | 1000GH-20UL |
| Product Category | High-Speed Fuse |
| Rated Current | 20 A |
| Rated Voltage | AC 1000 V / DC 1000 V |
| Breaking Capacity | AC 1000 V: 100 kA; DC 1000 V (L/R 3 ms): 100 kA |
| Minimum Breaking Current | 6 × rated current |
| Maximum Arc Voltage | 2000 V |
| Pre-Arcing I²t | 30 A²s |
| Total I²t | 350 A²s at AC 1000 V and 100 kA |
| Power Loss | 4.5 W |
| Recognition | UL Recognized |
Typical applications include semiconductor protection, power converters, inverters, rectifiers, industrial drives, UPS systems, and other high-speed protection applications in power electronics.
Apexon Supply provides B2B sourcing support for the Hinode 1000GH-20UL, assisting procurement teams with verified specification review, replacement sourcing, and technical alignment.
Send the manufacturer part number, required quantity, and application details to request a B2B RFQ and confirm technical compatibility.
