Hinode 1000SPF350S High-Speed Fuse, 350 A, AC 1000 V/DC 800 V
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Hinode 1000SPF350S is a 1000SPF series square-body high-speed fuse rated at 350 A, with AC 1000 V / 100 kA and DC 800 V / 100 kA interrupting capacity data listed in the official Hinode 1000SPF datasheet. This page summarizes verified specifications to support procurement review, replacement sourcing, and technical comparison for industrial circuit protection requirements.
| Brand | Hinode |
| MPN | 1000SPF350S |
| Series | 1000SPF |
| Fuse Type | Square-body high-speed fuse |
| Rated Current | 350 A |
| Rated Voltage / Interrupting Capacity | AC 1000 V / 100 kA; DC 800 V (L/R 10 ms) / 100 kA |
| Minimum Interrupting Current | 7 x rated current at AC 1000 V / DC 800 V |
| Maximum Arc Voltage | 2000 V |
| Melting I²t | 16.0 x 10^3 A²s |
| Clearing I²t at AC 1000 V / 100 kA | 157.0 x 10^3 A²s |
| Power Loss | 60 W |
| Dimensions | A 60 mm; B 73 mm; C 43 mm; D 66 mm |
| Mounting Thread | M10, depth 10 mm |
| Mass | 800 g |
| Blown-Fuse Indication | Standard |
| Table Condition | Ta = 25 degC |
Typical applications include industrial circuit protection, power equipment maintenance, control panel replacement review, and systems where the 1000SPF square-body fuse format, 350 A current rating, and specified AC/DC voltage ratings must be matched.
Apexon Supply supports B2B replacement sourcing for Hinode 1000SPF350S by aligning the MPN, current rating, voltage rating, interrupting capacity, I²t values, dimensions, mounting thread, and equipment requirements before procurement.
Send the MPN, required quantity, application details, and any nameplate or fuse label photos to request a B2B quote and technical alignment support.
