Hinode 250FH-400 Fast-Acting Fuse, 400A, 250V AC/DC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Hinode 250FH-400 is a fast-acting fuse rated at 400A and 250V AC/DC. Verified specifications include a 100kA breaking capacity, 14000 A²s pre-arcing I²t, and 85000 A²s total I²t at AC 250V for industrial circuit protection.
| Brand | Hinode |
| Manufacturer Part Number | 250FH-400 |
| Product Category | Fast-Acting Fuse |
| Rated Current | 400 A |
| Rated Voltage | 250 V AC/DC |
| Breaking Capacity | 100 kA AC/DC (L/R 10 ms) |
| Pre-Arcing I²t | 14000 A²s |
| Total I²t at AC 250V, 100kA | 85000 A²s |
| Power Loss | 40 W |
| Recommended Conductor | 240 mm² |
| Indicator | Without indicator |
| Dimensions A × B × C | 86 × 60 × 30 mm |
| Mass | 360 g |
Typical applications include industrial AC and DC power circuits, rectifiers, converters, power distribution equipment, and electrical systems requiring fast-acting overcurrent protection.
Apexon Supply provides B2B sourcing and replacement support for the Hinode 250FH-400, using verified technical specifications to assist procurement review and technical alignment.
Send the manufacturer part number, required quantity, and application requirements to request a B2B quote and industrial sourcing support.
