Hinode 750GH-80UL Industrial Fuse, 80A, 750V DC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Hinode 750GH-80UL is an industrial fuse in the 750GH series, rated at 80A with DC750V blocking capacity for circuit protection applications. Verified specifications include AC850V/DC750V rated voltage and blocking capacity, 553.8 A2s fusing value, and 18.0 W power loss.
| Brand | Hinode |
| Type | 750GH-80UL |
| Product Category | Industrial fuse |
| Rated Current | 80A |
| Rated Voltage and Blocking Capacity | AC850V-10kA / DC750V-10kA |
| Fusing Value | 553.8 A2s |
| Shutdown I2t | 9500 A2s at AC850V 10kA |
| Power Loss | 18.0 W |
| Dimensions | A 76.7 mm, B 62.7 mm, C 46 mm, D 27 mm max, E 18.5 mm max, F 9.5 mm, G 6.5 mm, H 18 mm, T 2 mm, W 12 mm |
| Weight | 41 g |
| Maximum Arc Voltage | 1900V |
Typical applications include circuit protection for industrial power systems, electrical equipment, and systems requiring high blocking performance. Review the rated current, rated voltage, interrupting performance, fuse dimensions, and holder requirements before replacement.
Apexon Supply supports B2B sourcing and replacement review for Hinode 750GH-80UL industrial fuses. Buyers can use the verified identifiers and specifications above for procurement comparison, technical alignment, and RFQ preparation.
Send the MPN, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
