Honeywell CN4605A1001 CN Series Non-Spring Return Damper Actuator, 230Vac, 5 Nm, 2-Position
Regular price
$70.00 USD
Regular price
Sale price
$70.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Honeywell CN4605A1001 is a robust, non-spring return direct-coupled damper actuator designed for precise 2-position (ON/OFF) control in commercial and industrial HVAC systems. Operating on standard 220V/230Vac supply voltage and delivering 5 Nm (44 lb-in) of torque, this dependable rotary actuator is engineered for reliable air damper control, VAV units, and ventilation flaps up to 10 sq.ft. (0.93 sq.m). Built into an IP54-rated enclosure with a universal shaft adapter and manual declutch override, it ensures long-term operational durability and ease of installation for enterprise automation environments.
| Product ID (MPN) | CN4605A1001 |
| Actuator Type | Non-Spring Return, Direct-Coupled |
| Control Signal | 2-Position (ON/OFF) |
| Nominal Voltage | 220V - 230Vac, 50/60 Hz |
| Torque Rating | 5 Nm (44 lb-in) |
| Max Damper Area | Up to 10 sq.ft. (Seal-less dampers) |
| Rotation Stroke | 95° ± 3° |
| Runtime for 90° | Approx. 90s (50/60Hz ac) |
| Mounting Shaft (Round) | 3/8 in. ... 5/8 in. |
| Mounting Shaft (Square) | 1/4 in. ... 1/2 in. (45° steps) |
| Protection Standard | IP54 (as per EN 60529) / Type 1 Enclosure |
| Mechanical Lifetime | 60,000 full stroke cycles / 1.5 million repositions |
| Feedback Signal | None |
| Internal End Switches | None |
| Ambient Operating Limits | -20... +60 °C (-5... +140 °F) |
| Weight | Approx. 1 lbs |
