Honeywell CN6110A1201 Non-Spring Return Damper Actuator, 24V Floating / 2-Position, 10 Nm, w/ 2 Aux Switches
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Honeywell CN6110A1201 is a premium non-spring return direct-coupled damper actuator built for reliable floating and 2-position control in commercial building HVAC systems. Operating on a 24Vac/dc supply and delivering 10 Nm (88 lb-in) of torque, it efficiently drives air dampers, VAV boxes, and ventilation flaps up to 20 sq.ft. (1.86 sq.m). This specific model distinguishes itself by incorporating two internal auxiliary end switches, allowing for precise position signaling and system interlocking. Enclosed in an IP54-rated housing with a manual declutch mechanism, it provides unmatched durability and seamless integration for enterprise automation workflows.
| Product ID (MPN) | CN6110A1201 |
| Actuator Type | Non-Spring Return, Direct-Coupled |
| Control Signal | Floating / 2-Position |
| Nominal Voltage | 24 Vac/dc, 50/60 Hz |
| Torque Rating | 10 Nm (88 lb-in) |
| Max Damper Area | Up to 20 sq.ft. (Seal-less dampers) |
| Internal Auxiliary Switches | 2 (Two) Internal End Switches (triggering at 5° and 85°) |
| Feedback Signal | None |
| Rotation Stroke | 95° ± 3° |
| Runtime for 90° | 90s (dc/60Hz ac), 110s (50Hz ac) |
| Mounting Shaft (Round) | 3/8 in. ... 5/8 in. |
| Mounting Shaft (Square) | 1/4 in. ... 1/2 in. (45° steps) |
| Protection Standard | IP54 (as per EN 60529) / Type 1 Enclosure |
| Mechanical Lifetime | 60,000 full stroke cycles / 1.5 million repositions |
| Ambient Operating Limits | -20... +60 °C (-5... +140 °F) |
