Honeywell CN6134A1003 Non-Spring Return Damper Actuator, 24V Floating / 2-Position, 34 Nm
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Honeywell CN6134A1003 is a heavy-duty, non-spring return direct-coupled damper actuator designed for precise floating and 2-position control in demanding commercial and industrial HVAC systems. Operating on a versatile 24Vac/dc power supply and delivering an exceptionally powerful 34 Nm (300 lb-in) of torque, this robust unit is engineered to efficiently drive oversized air dampers, VAV units, and large ventilation flaps up to approximately 85 sq.ft. (8.0 sq.m). Encased in an IP54-rated environmental housing and featuring a universal shaft adapter with a manual declutch mechanism, it ensures reliable long-term mechanical performance and simplified installation for enterprise building automation networks.
| Product ID (MPN) | CN6134A1003 |
| Actuator Type | Non-Spring Return, Direct-Coupled |
| Control Signal | Floating / 2-Position |
| Nominal Voltage | 24 Vac/dc, 50/60 Hz |
| Torque Rating | 34 Nm (300 lb-in) |
| Max Damper Area | Up to 8.0 sq.m / 85 sq.ft. (Seal-less dampers) |
| Rotation Stroke | 95° ± 3° |
| Runtime for 90° | Approx. 95s |
| Protection Standard | IP54 (as per EN 60529) / Type 1 Enclosure |
| Feedback Signal | None |
| Internal Auxiliary Switches | None |
| Ambient Operating Limits | -20... +60 °C (-5... +140 °F) |
| Mechanical Lifetime | 60,000 full stroke cycles / 1.5 million repositions |
