Honeywell CN7220A2007 Non-Spring Return Damper Actuator, 24Vac/dc Modulating, 20 Nm
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Honeywell CN7220A2007 is a high-performance, non-spring return direct-coupled damper actuator engineered for precise modulating control in heavy-duty commercial and industrial HVAC systems. Operating on a 24Vac/dc power supply, this robust actuator delivers a powerful 20 Nm (177 lb-in) of torque, capable of efficiently driving oversized air dampers, VAV units, and large ventilation flaps up to approximately 46 sq.ft. (4.0 sq.m). Featuring a durable IP54-rated enclosure, a universal shaft adapter, manual declutch mechanism, and a built-in voltage feedback signal, the CN7220A2007 ensures highly accurate positioning, long mechanical lifecycle, and seamless integration into advanced enterprise building automation networks.
| Product ID (MPN) | CN7220A2007 |
| Actuator Type | Non-Spring Return, Direct-Coupled |
| Control Signal | Modulating ((0)2...10 Vdc) |
| Nominal Voltage | 24 Vac/dc, 50/60 Hz |
| Torque Rating | 20 Nm (177 lb-in) |
| Max Damper Area | Up to 46 sq.ft. / 4.0 sq.m (Seal-less dampers) |
| Feedback Signal | Voltage Feedback Signal present ((0)2...10 Vdc) |
| Internal Auxiliary Switches | None |
| Rotation Stroke | 95° ± 3° |
| Runtime for 90° | Approx. 95s |
| Protection Standard | IP54 (as per EN 60529) / Type 1 Enclosure |
| Mechanical Lifetime | 60,000 full stroke cycles / 1.5 million repositions |
| Ambient Operating Limits | -20... +60 °C (-5... +140 °F) |
