Honeywell CN7505A3002 Non-Spring Return Damper Actuator, 24Vac/dc Modulating (4-20mA), 5 Nm
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Honeywell CN7505A3002 is a highly dependable, non-spring return direct-coupled damper actuator designed for precise modulating control in commercial and industrial HVAC applications. Operating on a 24Vac/dc power supply and tailored for 4-20mA control signals, this robust unit delivers a reliable 5 Nm (44 lb-in) of torque, making it ideal for accurately regulating air dampers, VAV units, and ventilation flaps up to 10 sq.ft. (0.93 sq.m). Housed in an IP54-rated environmental enclosure and featuring a universal shaft adapter with a manual declutch mechanism, it ensures accurate proportional damper positioning and a long mechanical lifespan for advanced enterprise building automation networks.
| Product ID (MPN) | CN7505A3002 |
| Actuator Type | Non-Spring Return, Direct-Coupled |
| Control Signal | Modulating (4-20mA / Voltage) |
| Nominal Voltage | 24 Vac/dc, 50/60 Hz |
| Torque Rating | 5 Nm (44 lb-in) |
| Max Damper Area | Up to 10 sq.ft. (Seal-less dampers) |
| Rotation Stroke | 95° ± 3° |
| Runtime for 90° | 90s (dc/60Hz ac), 110s (50Hz ac) |
| Mounting Shaft (Round) | 3/8 in. ... 5/8 in. |
| Protection Standard | IP54 (as per EN 60529) / Type 1 Enclosure |
| Mechanical Lifetime | 60,000 full stroke cycles / 1.5 million repositions |
| Ambient Operating Limits | -20... +60 °C (-5... +140 °F) |
