Honeywell CN7510A3002 Non-Spring Return Damper Actuator, 24Vac/dc Modulating (4-20mA), 10 Nm
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Honeywell CN7510A3002 is a highly dependable, non-spring return direct-coupled damper actuator engineered for precise modulating control in commercial and industrial HVAC building systems. Operating on a versatile 24Vac/dc power supply and purpose-built for 4-20mA control signals, this heavy-duty unit delivers a robust 10 Nm (88 lb-in) of torque, making it highly effective for accurately regulating air dampers, VAV units, and ventilation flaps up to 20 sq.ft. (1.86 sq.m). Housed in an IP54-rated environmental enclosure and featuring a universal shaft adapter with a manual declutch mechanism, the CN7510A3002 ensures highly accurate proportional damper positioning and a long mechanical lifecycle for demanding enterprise automation networks.
| Product ID (MPN) | CN7510A3002 |
| Actuator Type | Non-Spring Return, Direct-Coupled |
| Control Signal | Modulating (4-20mA / Voltage) |
| Nominal Voltage | 24 Vac/dc, 50/60 Hz |
| Torque Rating | 10 Nm (88 lb-in) |
| Max Damper Area | Up to 20 sq.ft. / 1.86 sq.m (Seal-less dampers) |
| Rotation Stroke | 95° ± 3° |
| Runtime for 90° | 90s (dc/60Hz ac), 110s (50Hz ac) |
| Mounting Shaft (Round) | 3/8 in. ... 5/8 in. |
| Mounting Shaft (Square) | 1/4 in. ... 1/2 in. (45° steps) |
| Protection Standard | IP54 (as per EN 60529) / Type 1 Enclosure |
| Mechanical Lifetime | 60,000 full stroke cycles / 1.5 million repositions |
| Ambient Operating Limits | -20... +60 °C (-5... +140 °F) |
