IDEC RH2B-UL RH Series Power Relay, DPDT, 10A, [Coil Voltage]
Regular price
$10.00 USD
Regular price
Sale price
$10.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The IDEC RH2B-UL is a high-capacity DPDT power relay from the RH Series, engineered for demanding industrial environments. Featuring a robust 10A contact rating and blade-style terminals, this relay provides reliable switching for motor loads and solenoid control. It is equipped with a non-polarized LED indicator for instant status verification and a check button (manual lever) for testing circuits, ensuring maximum uptime and simplified troubleshooting in control panel applications.
| Product ID (MPN) | RH2B-UL |
| Series | RH Series Compact Power Relays |
| Contact Configuration | DPDT (2 Form C) |
| Continuous Current (Amp) | 10A |
| Features | LED Indicator & Check Button |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Termination Style | Plug-in (Solder/Blade Terminal) |
| Operating Time | 20ms maximum |
| Dielectric Strength | 2000V AC (Between coil and contact) |
| Power Consumption | AC: 1.1 - 1.4VA / DC: 0.9W approx. |
