IDEC RH4B-UL RH Series Power Relay, 4PDT, 10A, [Specify Coil Voltage]
Regular price
$10.00 USD
Regular price
Sale price
$10.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The IDEC RH4B-UL is a heavy-duty 4PDT compact power relay from the RH series, engineered for high-density switching of up to 10A per pole. This robust plug-in relay features a blade-style terminal design and comes standard with a non-polarized LED indicator and a check button for manual circuit operation and testing. Designed with silver cadmium oxide contacts for superior arc resistance, it is a reliable choice for motor control, solenoid switching, and industrial automation panels requiring multi-pole power management.
| Product ID (MPN) | RH4B-UL |
| Series | RH Series Compact Power Relays |
| Contact Configuration | 4PDT (4 Form C) |
| Continuous Current (Amp) | 10A |
| Features | LED Indicator & Check Button (Manual Tester) |
| Allowable Contact Power | 2500VA AC / 300W DC |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Termination Style | Plug-in (14-blade Terminal) |
| Dielectric Strength | 2000V AC (Between coil and contact) |
| Mechanical Life | 50,000,000 operations minimum |
