Itelcond AYUX-HR332X350DC1 Aluminium Electrolytic Capacitor, 3300µF, 350V DC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Itelcond AYUX-HR332X350DC1 is an AYX-HR Series aluminium electrolytic capacitor rated at 3300µF and 350 V DC. This mounting stud capacitor uses screw terminals with M5 thread and a DC case code, supporting procurement review for industrial power electronics and replacement sourcing applications.
| Product ID / MPN | AYUX-HR332X350DC1 |
| Brand / Series / Category | Itelcond AYX-HR Series aluminium electrolytic capacitor |
| Nominal Capacitance | 3300µF |
| Rated Voltage | 350 V DC |
| Surge Voltage | 385 V DC |
| Ripple Current | 11.9 A at 85°C / 100Hz |
| ESR | 39 mΩ max at 100Hz |
| Mechanical Specs | DC case code, 76 mm x 107 mm |
| Mounting / Connection | Mounting stud, screw terminals with M5 thread |
| Climatic Category | 25/85/56 |
| Operating Temperature Range | -40°C to +85°C |
Typical applications include industrial power electronics, inverter assemblies, drive systems, DC bus circuits, power filtering equipment, and control systems requiring a 3300µF aluminium electrolytic capacitor rated for 350 V DC operation.
Apexon Supply supports B2B sourcing and replacement review for Itelcond AYUX-HR332X350DC1 capacitors. Buyers should verify capacitance, rated voltage, surge voltage, ripple current, ESR, dimensions, mounting style, and terminal type against the original equipment requirements before replacement.
Send the MPN, quantity, and application requirements to request a B2B quote for sourcing support and technical alignment.
