LTELCOND AYUX-HR332X450DF1 Aluminum Electrolytic Capacitor, 3300μF 450V, Screw Terminal (Mounting Stud), 76x147mm - Pack of 12

LTELCOND AYUX-HR332X450DF1 Aluminum Electrolytic Capacitor, 3300μF 450V, Screw Terminal (Pack of 12)

The LTELCOND AYUX-HR332X450DF1 is a high-performance aluminum electrolytic capacitor meticulously engineered for demanding industrial and power electronics applications. This robust capacitor features a 3300μF capacitance with a 450V rated voltage, making it suitable for high-power circuits requiring stable and efficient energy management. Its sturdy screw terminal (mounting stud) design ensures secure electrical and mechanical connections, pivotal for reliability in harsh operational environments. This component is optimized for extended operational life and exceptional stability, making it an ideal choice for systems requiring dependable filtering, energy storage, or smoothing functions.

Key Specifications:

• Manufacturer: LTELCOND
• Part Number: AYUX-HR332X450DF1
• Capacitance: 3300µF
• Rated Voltage: 450V
• Case Code: DF
• Dimensions (Φ x h): 76 x 147 mm
• Mounting Type: Screw Terminal (Mounting Stud)
• Typical Operating Temperature Range: -40°C to +85°C

Performance Characteristics (at 100Hz / 10KHz unless otherwise specified):

• Tangent Delta (TG δ) (100Hz): 0.10
• Equivalent Series Resistance (ESR) Max (100Hz): 48 mOhm
• Equivalent Series Resistance (ESR) Typical (100Hz): 36 mOhm
• Impedance (Z) Max (10KHz): 28 mOhm
• Ripple Current (I ripple) (100Hz):
  • 17.9 A at 55°C
  • 12.8 A at 85°C

Features & Benefits:

• High Power Density: Combines high capacitance and voltage within a compact DF case size, suitable for space-constrained designs.
• Low ESR and Impedance: Minimizes power loss and heat generation, enhancing overall system efficiency and reliability.
• Exceptional Ripple Current Capability: Designed to handle significant ripple currents, crucial for stable operation in power conversion applications.
• Robust Screw Terminal Construction: Ensures durable and vibration-resistant connections, extending service life in industrial settings.
• Long Life Performance: Engineered for reliability and prolonged operation in critical and continuous-duty environments.
• Industrial Grade: Built to meet the stringent demands of heavy-duty industrial and commercial equipment.

Typical Applications:

• Industrial Power Supplies
• Frequency Converters and Inverters
• Welding Equipment
• Motor Control and Drives
• Renewable Energy Systems (Solar Inverters, Wind Power Converters)
• Uninterruptible Power Supplies (UPS)
• Medical Imaging and Diagnostic Equipment Power Systems

Ordering Information: This product is delivered as a pack of 12 units, identified by the LTELCOND AYUX-HR332X450DF1 part number.
