Itelcond AYUX-HR103X400DJ1 AYX-HR Series Aluminium Electrolytic Capacitor, 10000uF, 400V
Regular price
$90.00 USD
Regular price
Sale price
$90.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Itelcond AYUX-HR103X400DJ1 is a high-capacity, high-reliability aluminium electrolytic capacitor engineered for demanding industrial power electronics. Featuring a threaded mounting stud for secure mechanical integration, this AYX-HR series component provides 10000uF at 400VDC, offering exceptional ripple current handling and extended life performance for large-scale inverters and energy storage systems.
| Product ID (MPN) | AYUX-HR103X400DJ1 |
| Series | AYX-HR (High Reliability / Mounting Stud) |
| Nominal Capacitance | 10000 uF |
| Rated Voltage (Vn) | 400 VDC |
| Surge Voltage | 440 VDC |
| Case Dimensions (DxH) | 76 x 222 mm (Case Code DJ) |
| Ripple Current (@85°C/100Hz) | 24.5 A |
| ESR (Max @100Hz) | 18 mΩ |
| Zmax (@10kHz) | 14 mΩ |
| Terminal Type | M5 Screw Terminal |
| Standards Compliance | CECC 30300, IEC 384-4 Long Life Grade |
