Jean Muller R5184353 Semiconductor Fuse, 100 A, 690 V
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Jean Muller R5184353 is a 100 A, 690 V AC semiconductor fuse with a 100 kA rated breaking capacity. This NH000-size, aR utilization-category fuse is designed for short-circuit protection of semiconductor components and features screw contacts and a top indicator.
| Manufacturer Part Number | R5184353 |
| Brand | Jean Muller |
| Product Category | Semiconductor Fuse |
| Rated Current | 100 A |
| Rated Voltage AC | 690 V |
| Rated Breaking Capacity AC | 100 kA |
| Utilization Category | aR |
| Fuse Size | NH000 |
| Contact Type | Screw contact |
| Hole Centre | 80 mm |
| Operating Joule Integral | 8,000 A²s |
| Pre-Arcing Joule Integral at 4 ms | 750 A²s |
| Indicator | Top indicator |
| Power Dissipation at Rated Current | 23.0 W |
Typical applications include short-circuit protection for semiconductor components in power-electronic equipment, industrial drives, converters, rectifiers, and related electrical systems. Confirm the current rating, voltage, breaking capacity, utilization category, size, and mounting arrangement against the original equipment requirements.
Apexon Supply provides B2B sourcing and replacement support for Jean Muller R5184353, helping procurement teams evaluate technical alignment and source hard-to-find circuit-protection components.
Send the MPN, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
