Jean Muller R5186023 Semiconductor Fuse, 350 A, 690 V
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Jean Muller R5186023 is an HLS00 semiconductor fuse rated at 350 A and 690 V AC. The label identifies an aR utilization category and 100 kA breaking capacity for industrial circuit-protection applications.
| Manufacturer Part Number | R5186023 |
| Brand | Jean Muller |
| Product Category | Semiconductor Fuse |
| Fuse Designation | HLS00 |
| Rated Current | 350 A |
| Rated Voltage AC | 690 V |
| Breaking Capacity | 100 kA |
| Utilization Category | aR |
| Standards Marking | VDE 0636, IEC 60269 |
Typical applications include short-circuit protection of semiconductor devices in industrial drives, converters, rectifiers, and other power-electronic systems. Verify the rated current, voltage, breaking capacity, utilization category, dimensions, and mounting arrangement before replacement.
Apexon Supply provides B2B sourcing and replacement support for Jean Muller R5186023, helping procurement teams review verified specifications and assess technical alignment for circuit-protection requirements.
Send the MPN, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
