Jianghai CD136 PK Series 220μF 450V Screw Terminal Aluminum Electrolytic Capacitor (P/N: ECG2WPK221MA053)
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Jianghai CD136 PK series is a professional-grade screw terminal aluminum electrolytic capacitor designed for high-voltage industrial applications. Engineered for use in professional inverters and power supplies, it offers a reliable 2000-hour service life at 105°C, providing stable performance and high ripple current resistance in a compact 36x53mm form factor.
| Product ID (MPN) | ECG2WPK221MA053 |
| Series | CD 136 PK |
| Nominal Capacitance | 220 μF |
| Rated Voltage | 450 V |
| Surge Voltage | 500 V |
| Capacitance Tolerance | ± 20% (20°C, 120Hz) |
| Typical ESR | 415 mΩ (20°C, 120Hz) |
| Rated Ripple Current | 1.1 Arms (105°C, 120Hz) |
| Dimensions (ΦDxL) | 36 x 53 mm |
| Operating Temperature | -25 to +105 °C |
| Load Life | 2000 hours @ 105°C |
| Compliance | RoHS Compliant |
