Johnson Controls VA9104-GGA-1S VA9104 Series Electric Non-Spring Return Valve Actuator, AC 24 V, 4 N·m
Regular price
$250.00 USD
Regular price
Sale price
$250.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Johnson Controls VA9104-GGA-1S is a VA9104 Series electric non-spring return valve actuator for direct-mount HVAC ball valve control. It provides proportional control from DC voltage or current command signals and is used for accurate positioning on compatible Johnson Controls VG1000 Series valve assemblies.
| Product ID (MPN) | VA9104-GGA-1S |
| Series | VA9104 Series |
| Product Type | Electric non-spring return valve actuator |
| Power Supply | AC 24 V |
| Power Requirement | AC 24 V +25%/-20% at 50/60 Hz, 2.9 VA, SELV Class III power supply |
| Control Type | Proportional control |
| Input Signal | DC 0(2) to 10 V or 0(4) to 20 mA with field-furnished 500 ohm resistor |
| Feedback Signal | DC 0 to 10 V or DC 2 to 10 V for 90° travel, corresponding to input signal span selection |
| Control Input Impedance | Voltage input: 200 kΩ; current input: 500 Ω with field-furnished 500 Ω resistor |
| Running Torque | 35 lb·in. / 4 N·m |
| Rotation Range | 93° ±3°, clockwise or counterclockwise |
| Travel Time | 60 seconds at 60 Hz / 72 seconds at 50 Hz for 90° rotation |
| Duty Life | 100,000 full-stroke cycles; 2,500,000 repositions at rated running torque |
| Audible Noise | 35 dBA maximum at 1 m |
| Electrical Connection | Integrated 48 in. / 1.2 m PVC cable with 0.75 mm² / 19 AWG conductors and 6 mm ferrule ends |
| Operating Ambient Temperature | -4°F to 140°F / -20°C to 60°C, 90% RH maximum, noncondensing |
| Storage Temperature | -40°F to 185°F / -40°C to 85°C, 90% RH maximum, noncondensing |
| Valve Compatibility | Johnson Controls VG1000 Series DN15, DN20, and DN25 ball valves |
| Compliance | UL Listed, cUL Listed, CE compliance, C-Tick Mark |
