KEMET ALS30A103QP400N Aluminum Electrolytic Capacitor, 10000 µF, 400 VDC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The KEMET ALS30A103QP400N is an ALS30 Series aluminum electrolytic capacitor rated at 10000 µF and 400 VDC. It features screw-terminal connections, chassis mounting, a 21.1 A ripple-current rating, and a service life of 20,000 hours at 85°C.
| Manufacturer Part Number | ALS30A103QP400N |
| Base Product Number | ALS30A |
| Brand | KEMET |
| Series | ALS30 |
| Capacitance | 10000 µF |
| Rated Voltage | 400 VDC |
| Tolerance | ±20% |
| Ripple Current | 21.1 A |
| ESR | 22 mOhm |
| Leakage Current | 6 mA |
| Termination Style | Screw terminal |
| Mounting Type | Chassis mount |
| Dimensions | 90 mm diameter × 131 mm length |
| Lead Spacing | 31.8 mm |
| Service Life | 20,000 hours at 85°C |
| Country of Origin | Great Britain |
Typical applications include motor drives, UPS systems, industrial power supplies, energy storage, and high-voltage filtering in power-conversion equipment. Verify capacitance, rated voltage, ripple current, ESR, dimensions, mounting, and terminal configuration before replacement.
Apexon Supply provides B2B sourcing and replacement support for the KEMET ALS30A103QP400N, helping procurement teams review verified specifications and assess technical alignment for industrial power systems.
Send the MPN, required quantity, and application requirements to request a B2B quote and sourcing review.
