KEMET ALS30A102KF450 ALS30 Series Aluminum Electrolytic Capacitor, 1000 µF, 450 V
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The KEMET ALS30 series is a high-performance aluminum electrolytic capacitor designed for industrial power electronics and motor control applications. This chassis-mount component offers excellent ripple current capability and long-term reliability in demanding thermal environments, making it an ideal choice for high-voltage DC link and inverter circuits.
| Product ID (MPN) | ALS30A102KF450 |
| Capacitance | 1000 µF |
| Voltage - Rated | 450 V |
| Tolerance | ±20% |
| ESR (Equivalent Series Resistance) | 118 mOhm @ 100 Hz |
| Impedance | 79 mOhm |
| Ripple Current @ Low Frequency | 6.5 A @ 100 Hz |
| Ripple Current @ High Frequency | 12.6 A @ 10 kHz |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Size / Dimension | 2.008" Dia (51.00mm) |
| Height - Seated (Max) | 4.134" (105.00mm) |
| Lead Spacing | 0.874" (22.20mm) |
| Lifetime @ Temp. | 18000 Hrs @ 85°C |
| Polarization | Polar |
