Mersen A13X50-4 Amp-trap Form 101 Semiconductor Protection Fuse, 50A, 130V AC
Regular price
$125.00 USD
Regular price
Sale price
$125.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mersen A13X50-4 is a 50A semiconductor protection fuse from the Amp-trap Form 101 series, designed to safeguard diodes and rectifiers in industrial applications. It features fast-acting, current-limiting characteristics with low I²t values to minimize thermal stress on sensitive components during fault conditions.
| Product ID (MPN) | A13X50-4 |
| Ampere Rating | 50A |
| Voltage Rating | 130V AC |
| Interrupting Rating (I.R.) | 8kA AC |
| Mounting Type | Type 4, Fig 2 |
| Dimensions | A: 2.66 in (67.6 mm), B: 1.13 in (28.7 mm), C: 1.16 in (29.5 mm), D: 2.19 in (55.6 mm), E: 1.91 in (48.5 mm), F: 0.31 in (7.9 mm), G: 0.88 in (22.4 mm), H: 0.19 in (4.8 mm) |
| Melting I²t | 240 A²s |
| Clearing I²t | 1,300 A²s (1 fuse), 840 A²s (1/2 fuses) |
| Recommended Fuse Block | 60306J |
| Features | Fast Acting, Current Limiting, Low I²t |
