Mersen A15QS7-2 High Speed Ferrule Fuse, 7A, 150V AC/DC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Mersen A15QS7-2 is an Amp-Trap A15QS Form 101 high speed ferrule fuse rated at 7A and 150V AC/DC. Its compact 1.50 x 0.41 in body is designed for clip mounting and semiconductor protection in space-constrained electrical assemblies. Supplied as a pack of 10 pieces.
| Manufacturer Part Number | A15QS7-2 |
| Series | Amp-Trap A15QS 150VAC/150VDC |
| Fuse Type | High Speed, Current-Limiting, Form 101 Ferrule |
| Ampere Rating | 7A |
| AC Voltage Rating | 150VAC |
| DC Voltage Rating | 150VDC |
| AC Interrupting Rating | 100kA |
| DC Interrupting Rating | 50kA |
| Mounting | Clip Mount |
| Terminal Style | Ferrule |
| Dimensions | 1.50 in length x 0.41 in diameter (38.1 x 10.4mm) |
| Compliance | UL Recognized; RoHS Compliant |
| Sales Quantity | 10 pieces |
Typical applications: Protection of diodes and other semiconductor devices in power conversion and industrial electrical circuits operating at up to 150VAC or 150VDC.
Apexon Supply provides B2B sourcing and replacement support for Mersen A15QS7-2, including technical alignment against current rating, voltage, interrupting capacity, ferrule dimensions and clip-mount requirements.
Send the MPN, required quantity and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
