Mersen D01GG40V4 Fuse-Link, D01 E14, 400 V AC 4 A
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Mersen D01GG40V4 is a D0 fuse-link in D01 size with E14 interface, rated for 400 V AC, 250 V DC, and 4 A circuit protection. It features an insulated body with top and bottom contacts made of nickel-plated or silver-plated copper alloy, with a brown indicator colour for identification.
| Product ID / MPN | D01GG40V4 |
| Secondary ID | W200809 |
| Brand / Category | Mersen / Fuse-Link |
| Size | D01 |
| Thread / Interface | E14 |
| Rated Voltage AC IEC | 400 V |
| Rated Voltage DC IEC | 250 V |
| Rated Current In | 4 A |
| Interrupting Rating AC IEC | 50 kA |
| Utilisation Category | gG |
| Power Dissipation at In | 1.6 W |
| Colour | Brown |
| Material | Insulated body; top and bottom contacts made of nickel-plated or silver-plated copper alloy |
| Dimensions | 36 mm x 11 mm |
| Weight | 6.6 g |
| Standard | DIN VDE 0636-3 |
| Package | 50 |
This fuse-link is used for protection of cables and power lines, limiting and cutting off unacceptable overcurrents and short-circuit currents. Typical applications include house incoming units, meter distribution units, distribution cabinets, installation cabinets, and fuse boxes.
Apexon Supply supports B2B replacement sourcing and technical alignment for Mersen D01GG40V4 and related D0 fuse-link components. Buyers should verify current rating, voltage rating, interrupting rating, utilisation category, body size, and E14 interface against the original equipment requirements before replacement.
Send the MPN, secondary item number, required quantity, and application requirements to request a B2B quote for sourcing support.
