Mersen D02GG44V50 Marine Fuse-Link, D02 E18, 440 V AC 50 A
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Mersen D02GG44V50 is a marine D0 fuse-link in D02 size with E18 interface, rated for 440 V AC, 250 V DC, and 50 A circuit protection. It features an insulated body with top and bottom contacts made of nickel-plated or silver-plated copper alloy, with a white indicator colour for identification.
| Product ID / MPN | D02GG44V50 |
| Secondary ID | J215702 |
| Brand / Category | Mersen / Fuse-Link |
| Design | Marine |
| Size | D02 |
| Thread / Interface | E18 |
| Rated Voltage AC IEC | 440 V |
| Rated Voltage DC IEC | 250 V |
| Rated Current In | 50 A |
| Interrupting Rating AC IEC | 50 kA |
| Utilisation Category | gG |
| Power Dissipation at In | 4.7 W |
| Colour | White |
| Material | Insulated body; top and bottom contacts made of nickel-plated or silver-plated copper alloy |
| Dimensions | 36 mm x 15 mm |
| Weight | 12.6 g |
| Standard | DIN VDE 0636-3 |
| Package | 50 |
This marine fuse-link is used for protection of cables and power lines, limiting and cutting off unacceptable overcurrents and short-circuit currents.
Apexon Supply supports B2B replacement sourcing and technical alignment for Mersen D02GG44V50 and related D0 fuse-link components. Buyers should verify current rating, voltage rating, interrupting rating, utilisation category, body size, marine design, and E18 interface against the original equipment requirements before replacement.
Send the MPN, secondary item number, required quantity, and application requirements to request a B2B quote for sourcing support.
