Mersen FD27GB66V8T / L076301 Semiconductor Fuse, 660 VDC, 8 A
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Mersen FD27GB66V8T, Item number L076301, is a Protistor® size 27x60 semiconductor protection fuse rated 8 A at 660 VDC. The fuse has a gR speed/characteristic and striker configuration.
| Catalog number | FD27GB66V8T |
| Item number | L076301 |
| Rated voltage DC | 660 V |
| Rated current | 8 A |
| Speed / Characteristic | gR |
| Product Size | 27x60 |
| Configuration | With striker |
| Watt Loss @0.8In | 1.2 W |
| Watt Loss @In | 2 W |
| Max. Interrupting Rating IR | 50 kA @ Rated Voltage, L/R = 15 ms |
| Package | 10 |
Typical applications: rectifiers, inverters, traction auxiliary circuits, UPS systems, and reduced voltage motor starters.
Apexon Supply provides B2B sourcing and replacement support for Mersen semiconductor protection fuses to support procurement review, technical alignment, and lifecycle sourcing requirements.
Request a B2B quote using Catalog number FD27GB66V8T or Item number L076301, together with the required quantity and application requirements.
