Mersen FR22UA69V20 / T081391 High-Speed Cylindrical Fuse, 20 A, 690 V AC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mersen FR22UA69V20 is a PROTISTOR® high-speed cylindrical semiconductor protection fuse with a 22x58 mm body, 20 A rated current, and 690 V AC IEC rated voltage. FR22UA69V20 is the Catalog Number, and T081391 is the manufacturer Reference Number. The product designation is 6,900 CP URGA 22.58 20, with an aR characteristic and configuration without indicator.
| Catalog Number | FR22UA69V20 |
| Reference Number | T081391 |
| Designation | 6,900 CP URGA 22.58 20 |
| Rated Current | 20 A |
| Rated Voltage AC (IEC) | 690 V |
| Speed / Characteristic | aR |
| Size | 22x58 mm |
| Configuration | Without indicator |
| Standard | IEC 60269-1 and IEC 60269-4 |
Apexon Supply provides B2B sourcing, replacement sourcing, and technical alignment support for Mersen FR22UA69V20 / T081391 and related semiconductor circuit protection components.
Send Catalog Number FR22UA69V20 or Reference Number T081391, required quantity, and application requirements for RFQ support. Most qualified RFQs receive a response or quote within 12 hours.
