MIRO NH00C 32A NH00 Low Voltage Fuse Link, 32A, 500V/660V gL
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The MIRO NH00C 32A is a compact low voltage NH fuse link that delivers full‑range general protection (gL/gG) for 500V/660V industrial circuits. Rated at 32 A and built in the size‑000 format, it provides reliable selective protection for feeders, motor circuits, and control panels. Compliant with IEC 60269‑2‑1, this fuse offers high breaking capacity and excellent current‑limiting performance.
| Product ID (MPN) | NH00C 32A |
| Rated Voltage | 500 V AC / 660 V AC |
| Rated Current | 32 A |
| Fuse Characteristic | gL/gG (full‑range general protection) |
| Rated Breaking Capacity | 120 kA (500 V) / 50 kA (660 V) |
| Power Dissipation (at 32 A) | 3.0 W |
| Rated Frequency | 45 – 62 Hz |
| Size Code | 000 (NH00) |
| Overall Dimensions (L × W × H) | 78.5 mm × 35 mm × 49.5 mm |
| Weight | 132 g |
| Blade Material | Silver‑plated copper |
| Body Material | High‑strength ceramic |
| Applicable Standards | IEC 60269‑2‑1, VDE 0636‑2 |
